Product Range
  •  Worm Gearboxes:
Compact units providing high reduction ratios, ideal for increasing torque output while maintaining a small footprint. They feature self-locking capabilities to hold valves in position without additional brakes.
  •  Bevel Gear Operators:
Provide efficient right-angle torque transmission with low backlash. Suitable for applications requiring compact installation and smooth operation.
  •  Manual and Motorized Gear Operators:
Options for manual override to motorized systems, ensuring continuous operation during power outages or system failures.

Technical Highlights
  •  Torque capacity: From 100 Nm to over 50,000 Nm
  •  Materials: High-strength cast iron, stainless steel, and hardened steel gears
  •  Mounting: Flange and shaft interfaces customizable to industry standards (ISO, DIN, ANSI)
  •  Sealing: IP65/IP67 rated for dust and water protection

Benefits
  •  High torque multiplication for large valves
  •  Robust, corrosion-resistant materials for long service life
  •  Low maintenance with sealed lubrication
  •  Flexible installation options with manual override capability

Typical Applications
  •  Large gate, globe, and ball valves in water, oil & gas
  •  Power plant damper controls
  •  Steel and heavy manufacturing industries
  •  Mining and mineral processing

Frequently Asked Questions (FAQ)

1: What types of gearboxes do you offer?
A: We offer worm gearboxes, bevel gear operators, and customized gearbox solutions designed for torque multiplication and valve actuation.

2: Can the gearboxes be used for manual override?
A: Yes, many of our gearboxes come with manual override options to allow valve operation during power failures or motor issues.

3: What maintenance is required for gearboxes?
A: Our gearboxes are designed for low maintenance with sealed-for-life lubricated bearings and gears. Periodic inspection for wear and lubrication condition is recommended depending on application severity.
